For transparent interior structures
Maximum transparency without vertical profiles.

System 3500

All-glass double-glazed wall

The System 3500 has been reduced to the essentials, whilst offering maximum transparency and high noise protection. The double-glazed system without vertical posts provides an elegant ambience and is particularly suitable for corridors.

  • Design: All-glass construction without vertical posts
  • Version: Double glazing 10 – 12 mm toughened glass/laminated glass
  • Element type: All-glass, ceiling-high
  • Surface: Anodised or powder-coated aluminium profiles
  • Dimensions: Width: Up to max. 1300 mm / Height: Up to max. 3000 mm
  • Wall thickness: 100 mm
  • Glass edging: Bonding/cross-profile dry joint
  • Doors: Solid doors, aluminium frame doors, Structural Glazing doors, all-glass doors
  • Sound insulation: 40 – 47 dB


  • Partition wall 3500 - Skyoffice, Waiblingen
  • Partition wall 3500 - Skyoffice, Waiblingen
  • Partition wall 3500 - Skyoffice, Waiblingen
  • Partition wall 3500 - Skyoffice, Waiblingen
  • Partition wall 3500 - Skyoffice, Waiblingen
  • Partition wall 3500 - Skyoffice, Waiblingen
  • Partition wall 3500 - Fully glazed system

Technical details

The System 3500 with double glazing can be created in countless variations. Here you will find some solutions and standard details. Your Strähle planning consultant will be pleased to provide you with information on individual solutions suited to your project. Obtain an obligation-free quote in your area.

CAD details you will find at planning tool for architects.

Case studies

This is how our finished solutions look. Inspiration and examples for innovative office designs, implemented with System 3500 partition walls.

Downloads

Technical documentation and planning examples can be found here.
